Onkyo - HT-S5805

What an awesome way to experience game-changing Dolby Atmos® sound! Everything you need to create a face-melting entertainment system is right here in one simple package, starting with a 100 W/Ch A/V receiver that connects all your media players and sends video to the TV via a single HDMI® cable—from your old analog game consoles to the latest 4K/60 Hz video with 4:4:4 color space and 21:9 cinema aspect.

  • 5.1.2 Ch, 100W Per Ch
  • Description

    • What an awesome way to experience game-changing Dolby Atmos® sound! Everything you need to create a face-melting entertainment system is right here in one simple package, starting with a 100 W/Ch A/V receiver that connects all your media players and sends video to the TV via a single HDMI® cable—from your old analog game consoles to the latest 4K/60 Hz video with 4:4:4 color space and 21:9 cinema aspect. Want full Smart TV capabilities? Plug a media streaming stick into the rearside STRM Box port and enjoy a wealth of audio and video streaming apps. Once you’ve connected the speaker system—which allows multidimensional Atmos soundtracks to flow above and around you—AccuEQ optimizes the sound to suit the unique shape of your room. We’ve also included Bluetooth technology so you can hear streamed audio with Onkyo’s legendary clarity and dynamism. Unleash tomorrow’s entertainment at home today!

  • Specification - A/V RECEIVER

    • A/V RECEIVER

      1. Supports Dolby Atmos® up to 5.1.2 Channels
      2. 4K/60 Hz-Capable HDMI® Terminals with 4:4:4 Color Space for UltraHD Entertainment (4 In/1 Out)
      3. Bluetooth Version 2.1 + EDR Capability (Compatible Profile: A2DP v1.2, AVRCP v1.3)
      4. Advanced Music Optimizer to Improve Compressed Digital Audio Quality (Bluetooth Audio Included)
      5. Phase-Matching Bass Boost for Deep Bass and Clear Mid-Range
      6. AccuEQ Room Acoustic Calibration
      7. WRAT (Wide Range Amplifier Technology)
      8. H.C.P.S. (High Current Power Supply) Massive High Power Transformer
      9. Discrete Output Stage Circuitry
      10. PLL (Phase Locked Loop) Jitter-Cleaning Circuit Technology for S/PDIF Audio
      11. Dolby® TrueHD and DTS-HD Master Audio™ Decoding
      12. HDMI Support for 4K/60 Hz, 3D, Audio Return Channel, DeepColor™, x.v.Color™, LipSync, Dolby Atmos®, Dolby® TrueHD, DTS-HD Master Audio™, DVD-Audio, Super Audio CD, Multichannel PCM, and CEC
      13. TI Burr-Brown 192 kHz/24-bit DAC for All Channels
      14. Advanced 32-bit DSP Chip
      15. 4 DSP Modes for Gaming: Rock, Sports, Action, and RPG
      16. Theater-Dimensional Virtual Surround Function
      17. CinemaFILTER™
      18. Direct Mode
      19. Double Bass Function
      20. Non-Scaling Configuration
      21. A-Form Listening Mode Memory
      22. STRM Box Port (Rear) for Powering Media Streaming Sticks
      23. 2 Component Video Inputs (Rear)
      24. 3 Composite Video Inputs (1 Front/2 Rear)
      25. 3 Digital Audio Inputs (2 Optical and 1 Coaxial)
      26. 7 Analog Audio Inputs (1 Front/6 Rear)
      27. Subwoofer Pre-Out
      28. Headphone Jack
      29. Crossover Adjustment (40 ⁄ 50 ⁄ 60 ⁄ 70 ⁄ 80 ⁄ 90 ⁄ 100 ⁄ 120 ⁄ 150 ⁄ 200 Hz)
      30. A/V Sync Control (Up to 500 ms in 10 ms Steps at 48 kHz)
      31. Overlaid On-Screen Display (OSD) via HDMI with Quick Set-Up
      32. HDMI Passthrough Function
      33. Tone Control (Bass/Treble) for Front L/R Channels
      34. 3-Mode Display Dimmer (Normal/Dim/Dimmer)
      35. 40 FM/AM Random Presets
      36. RIHD (Remote Interactive Over HDMI) for System Control
      37. Full-Function RI (Remote Interactive) Remote Control
  • Specification - SPEAKER SYSTEM

    • SKF-594 2-Way Bass Reflex Front Speakers/Full-Range Acoustic-Suspension Height Speakers

      1. 12 cm Cone Woofer
      2. 2.5 cm Balanced-Dome Tweeter
      3. 8 cm Cone (Separately Powered By Height Channel)
      4. Max. Input Power: 130 W
      5. Wall-Mounting Capability

      SKC-594 2-Way Bass Reflex Center Speaker

      1. 8 cm Cone Woofer x 2
      2. 2.5 cm Balanced-Dome Tweeter
      3. Max. Input Power: 130 W
      4. Wall-Mounting Capability

      SKR-594 Full-Range Acoustic-Suspension Surround Speakers

      1. 8 cm Cone
      2. Max. Input Power: 130 W
      3. Wall-Mounting Capability

      SKW-658 Bass Reflex Powered Subwoofer

      1. 20 cm Cone
      2. Rated Output Power: 80 W (Minimum Continuous Power, 4 Ohms, 100 Hz, 1%, IEC)
      3. Energy-Saving High Power Amplifier
      4. Down-Firing Design
  • General Specifications

    • A/V Receiver

      1. Power Output: 100 W/Ch (6 Ohms, 1 kHz, 1% THD, 1 Channel Driven, IEC);
      2. 100 W/Ch (6 Ohms, 1 kHz, 1% THD, 1 Channel Driven, JEITA)
      3. Frequency Response: 10 Hz–100 kHz/+1 dB, -3 dB (Direct Mode)
      4. Dimensions (W x H x D): 435 x 160 x 328 mm
      5. Weight: 8.0 kg

      Speaker System

      1. Frequency Response:
      2. Front 55 Hz–50 kHz
        Height 80 Hz–20 kHz
        Center 65 Hz–50 kHz
        Surround 80 Hz–20 kHz
        Subwoofer 27 Hz–150 Hz
      3. Dimensions (W x H x D):
      4. Front/Height 155 x 467 x 183 mm
        Center 409 x 115 x 121 mm
        Surround 115 x 230 x 96 mm
        Subwoofer 230 x 425 x 410 mm
      5. Weight:
      6. Front/Height 3.6 kg
        Center 2.2 kg
        Surround 1.0 kg
        Subwoofer 7.7 kg
